Brand: Belden
|
SKU:
2A-1802-B-7
Belden 27916A 0105000 | TC VN/PVC, 2 Conductor #18 Stranded Bare Copper, PVC-Nylon Insulation E2, Black PVC Jacket, 600V
Regular price
$1.47
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden 27916A 0105000 | TC VN/PVC, 2 Conductor #18 Stranded Bare Co...
Regular price
$1.47
Unit price
Description
Description
Belden 27916A 0105000 | TC VN/PVC, 2 Conductor #18 Stranded Bare Copper, PVC-Nylon Insulation E2, Black PVC Jacket, 600V
UL Type TC (1277) PVC-Nylon/PVC, 2 Conductor 18AWG (7x26) Bare Copper, PVC-NYL Insulation E2 Color Code, Black PVC Outer Jacket, 600V TC 150V NPLF 90C Wet/Dry SUN RES DIR BUR.
Specifications
Specifications
Belden - 27916A 0105000 - Specifications
| Element | Conductor(s) |
|---|---|
| No. of Elements | 2 |
| Size | 18 AWG |
| Stranding | 7x26 |
| UL Temperature | 90°C Dry, 90°C Wet |
| Stationary Min. | 0.732 in (18.6 mm) |
| Installation Min. | 0.915 in (23.2 mm) |
| Max. Pull Tension | 45 lbs (20 kg) |
| Bulk Cable Weight | 31 lbs/1000ft |
| Environmental Suitability | Indoor, Outdoor, Sunlight Resistance, Burial |
| Flammability / Reaction to Fire | UL1685 UL Loading, IEEE 1202 FT4 |
| NEC / UL Compliance | Article 336, NPLF, TC, TFFN |
| European Directive Compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC Compliance | China RoHS II (GB/T 26572-2011) |
