Brand: Belden
|
SKU:
323-321-1601-MT-B
Belden 31T1601 | 300V, (1 tr) 16 AWG (7x24) BC, PVC/PVC, Foil Shield, PLTC/ITC, CMG
Regular price
$3.00
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden 31T1601 | 300V, (1 tr) 16 AWG (7x24) BC, PVC/PVC, Foil Shiel...
Regular price
$3.00
Unit price
Brand: Belden
|
SKU:
323-321-1601-MT-B
Regular price
$3.00
Unit price
Shipping calculated at checkout.
Description
Description
Belden 31T1601 | 300V, (1 tr) 16 AWG (7x24) BC, PVC/PVC, Foil Shield, PLTC/ITC, CMG
Belden - 31T1601 - Features
- UL Instrumentation
- 1 Triad 16AWG (7x24) Bare Copper
- PVC Insulation E1 Color Code
- Overall Beldfoil® Shield,
- Black PVC Outer Jacket
- PLTC ITC CMG AWM 2464 SUN RES
Specifications
Specifications
Belden - 31T1601 - Specifications
| Conductor Element | Triad(s) |
|---|---|
| No. of Elements | 3 |
| Size | 16 AWG |
| Stranding | 7x24.5 |
| Material | BC - Bare Copper |
| Insulation Element | Triad(s) |
| Material | PVC - Polyvinyl Chloride |
| Nom. Thickness | 0.016 in (0.41 mm) |
| Nom. Insulation Diameter | 0.090 in mm |
| Shield Type | Tape |
| Material | Bi-Laminate (Alum+Poly) |
| Coverage | 100% |
| Drainwire Type | 20 AWG (7x28) TC |
| Nom. Conductor DCR | 4.2 Ohm/1000ft |
| Max. Current | 12.6 Amps per Conductor at 30ºC |
| UL Voltage Rating | 300 V (PLTC), 300 V (CMG) |
| Temperature | 105°C |
| Operating | 30°C To +105°C |
| Stationary Min. | 2.71 in (68.8 mm) |
| Installation Min. | 2.71 in (68.8 mm) |
| Max. Pull Tension | 119.7 lbs (54.30 kg) |
| Bulk Cable Weight | 51 lbs/1000ft |
