Brand: Belden
|
SKU:
B5300F1-5000
Belden 5300F1 0085001 | 18-2C STR Tnc PVC Foil Shd, Waterblocking Tape Pvc, Jacket Gray Cm 5K
Regular price
$1.74
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden 5300F1 0085001 | 18-2C STR Tnc PVC Foil Shd, Waterblocking T...
Regular price
$1.74
Unit price
Description
Description
Belden 5300F1 0085001 | 18-2C STR Tnc PVC Foil Shd, Waterblocking Tape Pvc, Jacket Gray Cm 5K
Security & Sound Cable, Rated-CM, 2-18 AWG stranded tinned copper conductors with PVC insulation, waterblocking tape, Beldfoil® shield and PVC jacket with ripcord
Specifications
Specifications
Belden - 5300F1 0085001 - Applications
- Security System
- Intercom/PA
- Audio/Speaker
- Power-Limited Controls
- Noisy & Wet Location
- Below-Grade Duct
Belden - 5300F1 0085001 - Specifications
| Conductor Count | 2 Conductors |
|---|---|
| Conductor Material | Tinned Copper |
| Conductor Size | 18 Awg (American Wire Gauge) |
| Conductor Type | Stranded Conductor |
| Fire Rating | General Purpose |
| Insulation Material | PVC-Polyvinyl Chloride |
| Jacket Material | Pvc-Polyvinyl Chloride |
| NEC Rating | Ul Listed Art 800 |
| Screen/Shield | Yes |
| Screen/Shield Type | Foil Shielded - Alum/Mylar |
| Shield Construction | Overall Shield & Drain |
| UNSPSC Code | 26121524 |
| Size | 18 AWG |
| Stranding | 7x26 |
| UL Temperature | 105°C |
| Operating Temperature | -20°C to +105°C |
| Stationary Min. | 2.2 in (56 mm) |
| Installation Min. | 2.2 in (56 mm) |
| Bulk Cable Weight | 27 lbs/1000ft |
| Sustainability | Product Lens™, Environmental Product Declaration (EPD) Available |
