Brand: Belden
|
SKU:
B5302F1-2-1000
Belden 5302F1 0021000 | 18-4c Str Tnc Pvc Foil Shdpvc Jacket Red Direct Burial water block Rohs
Regular price
$1.46
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden 5302F1 0021000 | 18-4c Str Tnc Pvc Foil Shdpvc Jacket Red Di...
Regular price
$1.46
Unit price
Description
Description
Belden 5302F1 0021000 | 18-4c Str Tnc Pvc Foil Shdpvc Jacket Red Direct Burial water block Rohs
Security & Sound Cable, Rated-CMG-FPL-PLTC, 4-18 AWG stranded tinned copper conductors with PVC insulation, waterblocking tape, Beldfoil® shield and PVC jacket
Specifications
Specifications
Belden - 5302F1 0021000 - Applications
- Security System
- Intercom/PA
- Audio/Speaker
- Power-Limited Controls
- Noisy & Wet Location
- Below-Grade Duct
Belden - 5302F1 0021000 - Specifications
| No. of Elements | 4 |
|---|---|
| Size | 18 AWG |
| Stranding | 7x26 |
| Material | TC - Tinned Copper |
| Operating Temperature | -30°C to +105°C |
| Stationary Min. | 2.6 in (66 mm) |
| Installation Min. | 2.6 in (66 mm) |
| Bulk Cable Weight | 45 lbs/1000ft |
| Flammability / Reaction to Fire | UL 1685 FT4 Loading, FT4, IEEE 1202 |
| Putup Type | Reel |
| Length | 1,000 ft |
