Brand: Belden
|
SKU:
B5302U1-1000
Belden 5302U1 0101000 | Multi-Conductor - Water-Blocked 4 18 Awg PVC Pvc Black
Regular price
$1.46
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden 5302U1 0101000 | Multi-Conductor - Water-Blocked 4 18 Awg PV...
Regular price
$1.46
Unit price
Description
Description
Belden 5302U1 0101000 | Multi-Conductor - Water-Blocked 4 18 Awg PVC Pvc Black
18 AWG stranded (7x27) tinned copper conductors, PVC insulation, water-blocking tape, PVC jacket.
Specifications
Specifications
Belden - 5302U1 0101000 - Applications
- Security System
- Intercom/Pa
- Audio/Speaker
- Power-Limited Controls
- Wet Location
- Below-Grade Duct
Belden - 5302U1 0101000 - Specifications
| Conductor Count | 4 Conductors |
|---|---|
| Conductor Material | Tinned Copper |
| Conductor Size | 18 Awg (American Wire Gauge) |
| Conductor Type | Stranded Conductor |
| Fire Rating | General Purpose |
| Insulation Material | Pvc-Polyvinyl Chloride |
| Jacket Material | Pvc-Polyvinyl Chloride |
| NEC Rating | Ul Listed Art 760 - Fire Alarm |
| Screen/Shield | No |
| UNSPSC Code | 26121524 |
| No. of Elements | 4 |
| Stranding | 7x26 |
| Stationary Min. | 3.1 in (79 mm) |
| Installation Min. | 3.1 in (79 mm) |
| Color | Black |
| UPC | 612825159797 |
