Belden 6220UL 004U1000 | Fire Alarm Cable, Low Smoke PVC, Yellow, 16 AWG, 1000 ft. L, 2-Conductors, Plenum
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden 6220UL 004U1000 | Fire Alarm Cable, Low Smoke PVC, Yellow, 1...
Description
Description
Temperature Range
UL Temp Rating: 75 °C
Operating Temp Range: 0 °C To +75 °C
Mechanical Characteristics
Bulk Cable Weight: 23.5 lbs/1000ft
Max Recommended Pulling Tension: 62.4 lbs
Min Bend Radius/Minor Axis: 1.625 in
Standards
NEC Articles: 760
NEC/(UL) Specification: FPLP
Other Specification: California State Fire Marshall
Applicable Environmental and Other Programs
EU Directive 2000/53/EC (ELV): Yes
EU Directive 2003/11/EC (BFR): Yes
EU Directive 2003/96/EC (BFR): Yes
EU Directive 2011/65/EU (ROHS II): Yes
EU Directive 2012/19/EU (WEEE): Yes
EU Directive 2015/863/EU: Yes
EU Directive Compliance: EU Directive 2003/11/EC (BFR)
EU CE Mark: Yes
CA Prop 65 (CJ for Wire Cable): Yes
MII Order #39 (China RoHS): Yes
Flammability, LS0H, Toxicity Testing
UL Flammability: NFPA 262 Plenum Flame Test (UL910)
UL voltage rating: 300 V RMS
Specifications
Specifications
Specifications
| ECCN | EAR99 |
|---|---|
| Country of Origin | MX - Mexico |
| Color Family | Yellow |
| Length | 1000 ft. |
| Color | Yellow |
| Conductor Size | 16 AWG |
| Conductor Material | Bare Copper |
| Jacket Material | Low Smoke PVC |
| No. of Conductors | 2 |
