Belden 633938 008U1000 | Surveillance CATV and MATV Cable, Fluorinated Ethylene Propylene, 1-Coax, 1-Conductor, Grey, 1000 ft.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden 633938 008U1000 | Surveillance CATV and MATV Cable, Fluorina...
Description
Description
Standards
NEC Articles: 820
NEC/(UL) Specification: CATVP, CMP
CEC/C(UL) Specification: CMP
RG Type: 6/U Type
Series Type: Series 6
Applicable Environmental and Other Programs
EU Directive 2000/53/EC (ELV): Yes
EU Directive 2003/96/EC (BFR): Yes
EU Directive 2011/65/EU (ROHS II): Yes
EU Directive 2012/19/EU (WEEE): Yes
EU Directive 2015/863/EU: Yes
EU Directive Compliance: EU Directive 2003/11/EC (BFR)
EU CE Mark: Yes
Suitability
Suitability - Indoor: Yes
Flammability, LS0H, Toxicity Testing
C(UL) Flammability: FT6
UL Flammability: NFPA 262 Plenum Flame Test (UL910)
UL voltage rating: 300 V RMS
Specifications
Specifications
Specifications
| Length | 1000 ft. |
|---|---|
| Cable Type | Plenum |
| Conductor Size | 18 AWG |
| Conductor Material | Bare Copper |
| Jacket Material | Flamarrest |
| Insulation Material | Fluorinated Ethylene Propylene |
| No. of Conductors | 1 |
| Shielded | Aluminum Braid |
Documents and Downloads
Documents and Downloads
