Brand: Belden
|
SKU:
B9921-60
Belden 9921 | Lead Wire, #22 Stranded TC, PVC Insulation, AWM 1007 AWM 1569
Regular price
$1.46
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden 9921 | Lead Wire, #22 Stranded TC, PVC Insulation, AWM 1007 ...
Regular price
$1.46
Unit price
Description
Description
Belden 9921 | Lead Wire, #22 Stranded TC, PVC Insulation, AWM 1007 AWM 1569
Low Temp Plastic Lead Wire, 22AWG (7x30) Tinned Copper, PVC Insulation, AWM 1007 AWM 1569 CSA TYPE TR-64 TRSR-64.
Specifications
Specifications
Belden - 9921 - Specifications
| Element | Conductor(s) |
|---|---|
| No. of Elements | 1 |
| Size | 22 AWG |
| Stranding | 7x30 |
| UL Temperature | 105°C |
| Environmental Suitability | Indoor |
| Sustainability | CA Prop 65 |
| Flammability / Reaction to Fire | VW-1 |
| AWM Compliance | AWM 1007, AWM 1569 |
| CEC / C(UL) Compliance | TRSR-64 |
| European Directive Compliance | EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC Compliance | China RoHS II (GB/T 26572-2011) |
