Brand: Belden
|
SKU:
B9961-PR
Belden 9961 0091000 | Electronic Cable, 1 Conductor #20 Stranded TC, PVC-NYL Insulation, OA TC Braid, PVC Jacket
Regular price
$4.02
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden 9961 0091000 | Electronic Cable, 1 Conductor #20 Stranded TC...
Regular price
$4.02
Unit price
Description
Description
Belden 9961 0091000 | Electronic Cable, 1 Conductor #20 Stranded TC, PVC-NYL Insulation, OA TC Braid, PVC Jacket
Electronic, 1 Conductor 20AWG (19x32) Tinned Copper, PVC-NYL Insulation, Overall Tinned Copper Braid(90%) Shield, PVC Outer Jacket.
Specifications
Specifications
Belden - 9961 0091000 - Specifications
| Element | Conductor(s) |
|---|---|
| No. of Elements | 1 |
| Size | 20 AWG |
| Stranding | 19x32 |
| UL Temperature | 105°C |
| Stationary Min. | 1.09 in (27.7 mm) |
| Installation Min. | 1.09 in |
| Max. Pull Tension | 15 lbs (6.8 kg) |
| Bulk Cable Weight | 8 lbs/1000ft |
| Flammability / Reaction to Fire | VW-1 |
| Military Compliance | MIL-W-16878E/17 (insulated conductor) |
| European Directive Compliance | EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE) |
| APAC Compliance | China RoHS II (GB/T 26572-2011) |
| UNSPC Code | 26121613 |
