Brand: Belden | SKU: MM07-BNTC5E-04

Belden C501105007 | Patch Cord, PVC, Green, Cat 5e, 7 Ft. L, Non-Shielded, RJ-45

$10.92

Shipping calculated at checkout.

Low prices.

Price match guarantee
In-House Experts.

We know our products
Easy Returns.

Quick & Hassle Free
Superior Selection.

Extensive product catalog

Description

7 Ft., for high density hubs, telecommunications outlet connections, MUTO connections, consolidation point connections, patch panel connections, equipment connections.

Key Features

Made with small diameter Bonded-Pair cable for greater flexibility and higher density installations
Solid conductors improve attenuation and are needed in long patch cords and pigtails to eliminate the need for cable derating in open-office cabling
Built with improved strain relief and a flexible boot for optimum protection in high density installations
Wrap-around label on each cord for easier product identification and length sorting

Specifications

Suitable Applications: IBDN System 1200, TIA Category 5E, ISO Class D, 1000BASE-T, 100BASE-T
Insulation Material: PO - Polyolefin
Outer Jacket Material: PVC
Overall Nominal Diameter: 5.283 mm
Individual Cable Diameter: 6.096 mm
Boot Color: Translucent
Wiring Scheme: T568A/B
Plug / Jack Compatibility: RJ-45
Storage Temperature Range: -40 °C To +70 °C
Installation Temperature Range: -10 °C To +60 °C
Operating Temperature Range: -10 °C To +60 °C
Max. Recommended Pull Tension: 111.205 N
Min. Bend Radius (Overall Cable): 26.416 mm
Suitability - Indoor: Yes
Dielectric Strength: 1, 000 V RMS @ 60 Hz for 1 minute
Current Rating: 1.500 A
Insulation Resistance: 500 M-Ohm Minimum
Max. Contact Resistance: 20 m-Ohm

Standards

UL Rating: Riser
Other Standards: FCC Part 68, Subpart F, IEC 60603-7
EU Directive 2002/95/EC (RoHS): Yes
MII Order #39 (China RoHS): EUP 50
Telecommunications Standards: Category 5e - TIA 568.B.2, Category 5 - ISO/IEC 11801:2002 Ed.2
Safety Listing: ACA, Bi-national Standard Listed

Additional Specifications

ECCN	EAR99
Country of Origin	MX - Mexico
Color Family	Green
Length	7 ft.
Color	Green
Shielded	Unshielded
Cable Type	U/UTP
Category	Cat 5e
Connector Configurations	RJ45 to RJ45

Documents and Downloads

Belden ENT C501105007 Data Sheet
