Belden C601102012 | Modular Copper Patch Cord, PVC, Red, Cat 6+, Non Shielded, 24 AWG, RJ-45 to RJ-45,12 Ft. L

Specifications

• Suitable Applications: IBDN System 4800, IBDN System 3600, IBDN System 2400, TIA Category 6, ISO Class E, 1000BASE-T
• Conductor Material: BC - Bare Copper
• Insulation Material: PO - Polyolefin
• Outer Jacket Material: PVC - Polyvinyl Chloride
• Overall Cabling Fillers: Cross Web
• Overall Nominal Diameter: 0.225 in.
• Plug RJ-45 Material: Polycarbonate
• Boot Material: Elastomer
• Front Connection Blade Material: Phosphor Bronze with 50u inch Gold over Nickel Plating
• Boot Color: Translucent
• Plug / Jack Compatibility: RJ-45
• Termination: RJ-45
• Connection: Mated Connection
• Durabilities: 750 Cycles
• Storage Temperature Range: -40 °C to +70 °C
• Installation Temperature Range: -10 °C to +60 °C
• Operating Temperature Range: -10 °C to +60 °C
• Max. Recommended Pull Tension: 11.250 lb.
• Min. Bend Radius (Overall Cable): 1.040 in.
• Suitability: Indoor

Standards & Environmental Programs

• UL Rating: Riser
• Other Standards: FCC Part 68, Subpart F, IEC 60603-7
• EU Directive 2002/95/EC (RoHS): Yes
• Telecommunications Standards: Category 6 - TIA 568.C.2, ISO/IEC 11801:2002 Ed.2
• Safety Listing: Bi-national Standard Listed

Additional Specifications

• Belden ENT C601102012 Data Sheet
