Belden C6D1100010 | Modular Copper Patch Cord, PVC, Black, Cat6, Non Shielded, 28 AWG, RJ-45 to RJ-45 10 Ft. L

Specifications

• Suitable Applications: TIA Category 6, ISO Class E, 1000BASE-T, Support Power over Ethernet (up to 100W), Cisco UPOE (up to 60W) and Power over HDBase-T (up to 100W)
• Conductor Material: Tinned Copper
• Insulation Material: PE - Polyethylene
• Outer Jacket Material: PVC - Polyvinyl Chloride
• Overall Nominal Diameter: 3.810 mm
• Plug RJ-45 Material: Polycarbonate - UL94V-0
• Boot Material: Polycarbonate - UL94V-0
• Front Connection Blade Material: Phosphor Bronze with 50u inch Gold over Nickel Plating
• Boot Color: Translucent
• Plug / Jack Compatibility: RJ-45
• Termination: RJ-45
• Connection: Mated Connection
• Durabilities: 750 Cycles
• Storage Temperature Range: -40 °C to +75 °C
• Installation Temperature Range: 0 °C to +60 °C
• Operating Temperature Range: -20 °C to +75 °C
• Max. Recommended Pull Tension: 50.042 N
• Min. Bend Radius (Overall Cable): 14.732 mm
• Suitability - Indoor: Yes

Standards & Environmental Programs

• UL Rating: Riser
• Other Standards: FCC Part 68, Subpart F, IEC 60603-7
• EU Directive 2002/95/EC (RoHS): Yes
• Telecommunications Standards: ISO/IEC 11801:2002 Ed.2, TIA 568.2-D
• Safety Listing: c(UL)us Listed
• Other Specification: CEC/C(UL) Voltage Rating: 300 V RMS

Additional Specifications

• Belden ENT C6D1100010 Data Sheet
