Belden C6T1108007 | Patch Cord, PVC, Grey, Cat 6+, 7 Ft. L, Non-Shielded, RJ-45

Specifications

• Environmental Space: Riser
• Suitable Applications: IBDN System 4800, 3600 and 2400, TIA Category 6, ISO Class E, 1000BASE-T, 20 and 40 sec. flashing high intensity LED Battery operated, push button activated
• Total Number of Pairs: 4
• Overall Nominal Diameter: 0.238 in.
• Wiring Scheme: T568A/B-T568A/B
• Boot Elastomer Translucent
• Conductor BC - Bare Copper
• Front Connection Blades Phosphor Bronze with 50u inch Gold over Nickel Plating
• Inner Jacket PVC - Polyvinyl Chloride
• Insulation PO - Polyolefin
• Outer Jacket PVC - Polyvinyl Chloride
• Current Rating: 1.500 A
• Insulation Resistance: 500 M-Ohm Minimum
• Max Contact Resistance: 20 mOhm
• Installation Temp Range: -10 °C To +60 °C
• Storage Temp Range: -40 °C To +70 °C
• Operating Temp Range: -20 °C To +75 °C
• Min Bend Radius (Overall Cable): 1.040 in.
• Plug /Jack Compatibility: RJ-45
• Safety Listing: c(UL)us Listed

Standards

• UL Rating: Riser
• Data Category: Category 6+
• Telecommunications Standards: Category 6 - TIA 568-C.2, Class E - ISO/IEC 11801:2002 Ed.2 Amendment 2
• Other Standards: FCC Part 68, Subpart F, IEC 60603-7

Additional Specifications

• Belden ENT C6T1108007 Data Sheet
