Brand: Belden
|
SKU:
MM20-BNTEC6-02T
Belden CA21100020 | Patch Cord, PVC, Black, Cat 6A, 20 Ft. L, Non-Shielded, RJ-45
Regular price
$40.59
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden CA21100020 | Patch Cord, PVC, Black, Cat 6A, 20 Ft. L, Non-S...
Regular price
$40.59
Unit price
Brand: Belden
|
SKU:
MM20-BNTEC6-02T
Regular price
$40.59
Unit price
Shipping calculated at checkout.
Description
Description
20 Ft. 10GX patch cord bonded-Pair 4-Pair 24 AWG solid black.
Key Features
- Belden Bonded-Pair technology for extra robustness, performance and reliability
- Barcode tagging on each end of the cord is compatible with DCIM systems
- 100% factory tested and certified
Specifications
Specifications
Specifications
- Environmental Space: Riser
- Suitable Applications: IBDN System 10GX, TIA Category6A, ISO ClassEA, 10GBASE-T
- Total Number of Pairs: 4
- Overall Nominal Diameter: 0.265 in.
- Wiring Scheme: T568A/B-T568A/B
- Boot Elastomer - Translucent
- Conductor BC - Bare Copper
- Front Connection Blades Phosphor Bronze with 50u inch Gold over Nickel Plating
- Inner Jacket PVC - Polyvinyl Chloride
- Insulation PO - Polyolefin
- Outer Jacket PVC - Polyvinyl Chloride
- Current Rating: 1.500 A
- Insulation Resistance: 500 M-Ohm Minimum
- Max Contact Resistance: 20 mOhm
- Installation Temp Range: -10 °C To +60 °C
- Storage Temp Range: -40 °C To +70 °C
- Operating Temp Range: -20 °C To +75 °C
- Min Bend Radius (Overall Cable): 1.040 in.
- Plug /Jack Compatibility: RJ-45
- Safety Listing: c(UL)us Listed
Standards
- UL Rating: Riser
- Data Category: Category 6A
- Telecommunications Standards: Category 6A - TIA 568-C.2, Class EA - ISO/IEC 11801:2002 Ed.2 Amendment 2
- Other Standards: FCC Part 68, Subpart F, IEC 60603-7
Additional Specifications
| ECCN | EAR99 |
|---|---|
| Country of Origin | MX - Mexico |
| Color Family | Black |
| Length | 20 ft. |
| Color | Black |
| Shielded | Unshielded |
| Cable Type | U/UTP |
| Category | Cat 6A |
| Connector Configurations | RJ45 to RJ45 |
