Belden CA21108015 | Patch Cord, PVC, Grey, Cat 6A, 15 Ft. L, Non-Shielded, RJ-45

Specifications

• Suitable Applications: IBDN System 10GX, TIA Category 6A, ISO Class EA, 10GBASE-T
• Insulation Material: PO - Polyolefin
• Inner Jacket Material: PVC - Polyvinyl Chloride
• Overall Cabling Fillers: Cross Web
• Overall Nominal Diameter: 7.239 mm
• Individual Cable Diameter: 7.239 mm
• Boot Color: Translucent
• Wiring Scheme: T568A/B-T568A/B
• Plug / Jack Compatibility: RJ-45
• Storage Temperature Range: -40 °C To +70 °C
• Installation Temperature Range: -10 °C To +60 °C
• Operating Temperature Range: -10 °C To +60 °C
• Max. Recommended Pull Tension: 111.205 N
• Min. Bend Radius (Overall Cable): 26.416 mm
• Suitability - Indoor: Yes
• Dielectric Strength: 1, 000 V RMS @ 60 Hz for 1 minute
• Current Rating: 1.500 A
• Insulation Resistance: 500 M-Ohm Minimum
• Max. Contact Resistance: 20 m-Ohm

Standards

• UL Rating: Riser
• Other Standards: FCC Part 68, Subpart F, IEC 60603-7
• EU Directive 2002/95/EC (RoHS): Yes
• MII Order #39 (China RoHS): EUP 50
• Telecommunications Standards: Category 6A - TIA 568.B.2-10, ISO/IEC 11801:2002 Amendment 2
• Safety Listing: ACA, Bi-national Standard Listed

Additional Specifications

• Belden ENT CA21108015 Data Sheet
