Belden ENT 9807 0601000 | Multi-Conductor Low Capacitance Computer ...
Regular price
$9.28
Unit price
Brand: Belden
|
SKU:
B9807-1000
Regular price
$9.28
Unit price
Description
Description
28 AWG stranded (7x36) TC conductors, polypropylene insulation, overall Beldfoil (100% coverage) + TC braid shield (90% coverage), 28 AWG stranded TC drain wire, PVC jacket.
Specifications
Specifications
Additional Specifications
| Conductor Count | 5 PAIRS |
|---|---|
| NEC Rating | UL LISTED ART 725 CLASS 2 |
| Conductor Material | TINNED COPPER |
| Conductor Size | 28 AWG (AMERICAN WIRE GUAGE) |
| Conductor Type | STRANDED CONDUCTOR |
| Fire Rating | GENERAL PURPOSE |
| Insulation Material | PP-POLYPROPYLENE |
| Jacket Material | PVC-POLYVINYL CHLORIDE |
| Screen/Shield Type | BRAID OVER FOIL SHIELD |
| Screen/Shield | YES |
| Shield Construction | OVERALL ISOLATED FROM INDV |
| UNSPSC Code | 26121613 |
