Brand: Belden
|
SKU:
700985
Belden RVAMJKUTY-B24 | REV Connect Series, Cat 6A Modular Connector, Plastic, RJ-45, 1-Port, Unshielded, Yellow, 0.94 H x 0.64 W x 1.33 in. D
Regular price
$503.51
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Belden RVAMJKUTY-B24 | REV Connect Series, Cat 6A Modular Connector...
Regular price
$503.51
Unit price
Description
Description
REVConnect cat 6a 10GX UTP yellow modular jack. Ensure network reliability and uptime with a sophisticated insulation piercing mechanism that supports all conductor types.
Key Features
- Easy field termination and troubleshooting without twisted pair separation
- Safe in harsh settings, including exposure to oil, extreme temperatures, some corrosive gas and vibration with UL94 V-0 materials, EMI protection and E2/E3 ratings
- Reliable path to ground and withstands climatic chemicals and mechanical risks (crushing, bending, shock and vibration)
- IP20-rated design for enclosed racks and cabinets in industrial environments
- Capable of re-termination (up to 200 cycles) with enhanced insulation piercing mechanism
Specifications
Specifications
Standards & Environmental Programs
- UL Rating: UL94V-0
- IEEE Specification: Power Over Ethernet (PoE) IEEE 802.3at type 1 and 2 (up to 30W), IEEE802.3bt/D1.7 type 3 and 4 (up to
- 100W), CISCO UPOE (up to 60W), Power over HDBaseT (up to 100W)
- EU Directive 2002/95/EC (RoHS): Yes
- Telecommunications Standards: Category 6A - TIA 568.C.2, Category 6A - ISO/IEC 11801:2002 Ed.2
- Safety Listing: c(UL)us Listed
- Other Specification: UL 1863, IEC 60603-7, FCC part 68-F
Suitability
- Suitability - Indoor: Yes - Indoor
Additional Specifications
| ECCN | EAR99 |
|---|---|
| Brand | REVConnect |
| Series | 195 Series |
| Adapter Housing Color | Yellow |
| Flammability Rating | UL-rated 94V-0 |
| Insert Material | Plastic |
| Module Type | Modular Jack |
| Plating Material | Gold-Plated Copper Alloy |
| Wiring Configuration | T568A/T568B |
| Category | Cat 6A |
| Connector Type | RJ-45 |
