Burndy BIBS25010 | 1-Sided, 10-Conductor, Clear Insulated Multi-Tap...
Regular price
$165.77
Unit price
Brand: Burndy
|
SKU:
BIBS250-10
Regular price
$165.77
Unit price
Description
Description
Burndy BIBS25010 | 1-Sided, 10-Conductor, Clear Insulated Multi-Tap Connector
Clear Plastisol Covered, Single Side Entry, 10 Ports, #10 AWG - 250 kcmil. Al/Cu Rated. Oxide inhibitor is pre-installed.
Burndy - BIBS25010 - Features
- Clear Plastisol covered AL6061-T6 aluminum body saves times and lowers installation costs and eliminates taping
- Clear plastisol allows visual confirmation that conductor is properly inserted
- Oxide inhibitor pre-installed inhibits moisture and contaminants from entering the contact area
- Range-taking capability reduces number of connectors necessary to carry in inventory
Specifications
Specifications
Burndy - BIBS25010 - Specifications
| Catalog Number | BIBS25010 |
|---|---|
| Connector Type | Multi Tap |
| Hex Key | 5/16 |
| Insulation | Y |
| Insulation Type | Plastisol |
| Material | Aluminum |
| Number Of Ports | 10 |
| Physical Attribute - Number of Screws | 10 |
| Physical Attribute - Screw Type | Allen |
| Plated | No |
| Plating Type | Unplated |
| Temperature Rating | 194 |
| Trade Name | UNITAP™ |
| UPC | 781810232965 |
| UPC 14 Digit GTIN | 00781810232965 |
