Brand: Burndy
|
SKU:
BIBS250-8
Burndy BIBS2508 | 1-Sided, 8-Conductor, Dual-Rated Al/Cu, Clear Insulated Multi-Tap Connector
Regular price
$104.55
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Burndy BIBS2508 | 1-Sided, 8-Conductor, Dual-Rated Al/Cu, Clear Ins...
Regular price
$104.55
Unit price
Description
Description
Burndy BIBS2508 | 1-Sided, 8-Conductor, Dual-Rated Al/Cu, Clear Insulated Multi-Tap Connector
Clear Plastisol Covered, Single Side Entry, 8 Ports, #10 AWG - 250 kcmil. Al/Cu Rated. Oxide inhibitor is pre-installed.
Burndy - BIBS2508 - Features
- Clear Plastisol covered AL6061-T6 aluminum body saves times and lowers installation costs and eliminates taping
- Clear plastisol allows visual confirmation that conductor is properly inserted
- Oxide inhibitor pre-installed inhibits moisture and contaminants from entering the contact area
- Range-taking capability reduces number of connectors necessary to carry in inventory
Specifications
Specifications
Burndy - BIBS2508 - Specifications
| Application | For Indoor Use Only, Copper Or Stranded Aluminum |
|---|---|
| Catalog Number | BIBS2508 |
| Connector Type | Multi Tap |
| Hex Key | 5/16 |
| Insulation | Y |
| Insulation Type | Plastisol |
| Material | Aluminum |
| Number Of Ports | 8 |
| Physical Attribute - Number of Screws | 8 |
| Physical Attribute - Screw Type | Allen |
| Plated | No |
| Plating Type | Unplated |
| Sub Brand | UNITAP |
| Temperature Rating | 194 |
| Trade Name | UNITAP™ |
| Type | BIBS, Multi-Port |
| UPC | 781810131787 |
| UPC 14 Digit GTIN | 00781810131787 |
