Brand: Burndy
|
SKU:
BIBS600-5
Burndy BIBS6005 | 1-Sided, 5-Conductor, Dual-Rated Al/Cu, Clear Insulated Multi-Tap Connector
Regular price
$113.16
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Burndy BIBS6005 | 1-Sided, 5-Conductor, Dual-Rated Al/Cu, Clear Ins...
Regular price
$113.16
Unit price
Description
Description
Burndy BIBS6005 | 1-Sided, 5-Conductor, Dual-Rated Al/Cu, Clear Insulated Multi-Tap Connector
Clear Plastisol Covered, Single Side Entry, 5 Ports, #4 AWG-600 kcmil. Al/Cu Rated. Oxide inhibitor is pre-installed.
Burndy - BIBS6005 - Features
- Clear Plastisol covered AL6061-T6 aluminum body saves times and lowers installation costs and eliminates taping
- Clear plastisol allows visual confirmation that conductor is properly inserted
- Oxide inhibitor pre-installed inhibits moisture and contaminants from entering the contact area
- Range-taking capability reduces number of connectors necessary to carry in inventory
Specifications
Specifications
Burndy - BIBS6005 - Specifications
| Application | For Indoor Use Only, Copper Or Stranded Aluminum |
|---|---|
| Catalog Number | BIBS6005 |
| Connector Type | Multi Tap |
| Hex Key | 3/8 |
| Insulation | Y |
| Insulation Type | Plastisol |
| Material | Aluminum |
| Number Of Ports | 5 |
| Physical Attribute - Number of Screws | 5 |
| Physical Attribute - Screw Type | Allen |
| Plated | No |
| Plating Type | Unplated |
| Sub Brand | UNITAP |
| Temperature Rating | 194 |
| Trade Name | UNITAP™ |
| Type | BIBS, Multi-Port |
| UPC | 781810224120 |
| UPC 14 Digit GTIN | 00781810224120 |
