Burndy YA442NTCFX | 25019920 | Copper Compression Terminal, 2 Hole without Inspection Window, Standard Barrel, 1/2 Inch Stud

Burndy - YA442NTCFX | 25019920 - Features

• Internally beveled barrel end for easy cable insertion, connector clearly marked with wire size and type, die index and color coding, markings provide for inspectability along with ease of determining proper tooling recommended.
• Compression Terminal
• Tongue Angle: Straight
• Length: 7.14 Inch
• Barrel Style: Chamfered
• Bolt Hole Size: 0.52 Inch
• Stud Size: 1/2 Inch
• Barrel Type: Standard
• B
• Length: 3 Inch
• Pad Width: 2.18 InchHole to Hole Distance: 1.75 Inch
• Strip
• Number Of Holes: 2
• Wire Size: 750 KCMIL Flex, 750 KCMIL Copper Stranded, 777.7 KCMIL (1925/#24) DLO
• Type Of Plating: Tin
• Color Code: Yellow
• Index Number: L115
• Material: Copper
• Voltage Rating: 600 Volt - 35 Kilo-Volt
