Burndy YA44L2TC38FX45 | 510462 | Copper Compression Terminal, Bevel Entry, 2 Hole with Inspection Window

Burndy - YA44L2TC38FX45 | 510462 - Features

• Internally beveled barrel end for easy cable insertion, connector clearly marked with wire size and type, die index and color coding, markings provide for inspectability along with ease of determining proper tooling recommended.
• Compression Terminal
• Tongue Angle: 45 Degree
• Length: 4.71 Inch
• Tongue Type: Standard
• Barrel Style: Chamfered
• Bolt Hole Size: 0.39 Inch
• Stud Size: 3/8 Inch
• Thickness: 0.33 Inch
• B Length: 1.65 Inch
• Pad Width: 2.19 Inch
• Hole to Hole Distance: 1 Inch
• Strip Length: 1-5/8 Inch
• Number Of Holes: 2
• Wire Size: 750 KCMIL Flex, 750 KCMIL Copper Stranded, 777.7 KCMIL (1925/#24) DLO
• Type Of Plating: Tin
• Color Code: Yellow
• Index Number: L115
• Material: Copper
• Voltage Rating: 600 Volt - 35 Kilo-Volt
