Burndy YA8C2N | Compression Lug, Red Copper, 2-Hole, 8 AWG, Long Barrel, Die Index 49
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Burndy YA8C2N | Compression Lug, Red Copper, 2-Hole, 8 AWG, Long Ba...
Description
Description
BURNDY compression connectors are designed for reliable and controllable electrical connections. The complete installation is fully inspectable. They are high conductivity copper and operate cooler than the wire on which they are installed. The connectors withstand a wide range of electrical and environmental conditions, including current surges, temperatures, corrosion and vibrations, for a wide variety of applications. These features mean a consistently high quality connection at a low installed cost.
Specifications
Specifications
Burndy - YA8C2N - Specifications
| Manufacturer part number | YA8C2N |
|---|---|
| Brand Name | Burndy |
| Item Description | Compression Lug, Red Copper, 2-Hole, 8 AWG, Long Barrel, Die Index 49 |
| Barrel Type | Long Barrel |
| Barrel | Standard |
| Color Code | Red |
| Conductor Material | Copper |
| Conductor Size | 8 AWG |
| Die Index | 49 |
| Holes | 1 Hole |
| Inspection Hole | Without inspection Window |
| Insulation Material | Non-Insulated |
| Lug L x Tongue W | Tongue W: 0.83 in. |
| Lug Material | Copper |
| Material | Copper |
| Number of Holes | 2 Holes |
| Overall Length | 4.08 in. (103.63 mm) |
| Overall Width | 0.83 in. |
| Product Type | Compression Lug |
| Stud Hole Spacing | 1-3/4 in. |
| Tongue Angle | Straight |
| Tongue Thickness | 0.12 in. (3mm) |
| Tongue Type | Standard |
| Tongue Width | 0.83 in. |
| Voltage Rating | 35 kV |
