Burndy YAV25LTC14FX45 | 518530 | Hylug Copper Tubing Compression Lug, 1 Hole with Inspection Window

Burndy - YAV25LTC14FX45 | 518530 - Features

• Internally beveled barrel end for easy cable insertion, connector clearly marked with wire size and type, die index and color coding, markings provide for inspectability along with ease of determining proper tooling recommended.
• Tubing Compression Lug
• Tongue Angle: 45 Degree
• Length: 1.71 Inch
• Tongue Type: Standard
• Barrel Style: Chamfered
• Bolt Hole Size: 0.27 Inch
• Stud Size: 1/4 Inch
• Thickness: 0.12 Inch
• B Length: 0.69 Inch
• Pad Width: 0.83 Inch
• Length: 11/16 Inch
• Number Of Holes: 1
• Wire Size: 1/0 AWG Flex, 1/0 AWG Copper Stranded, 1/0 AWG (275/#24) DLO
• Type Of Plating: Tin
• Color Code: Pink
• Material: Copper
