Burndy YAV35M10 | Compression Terminal
Regular price
$18.45
Unit price
Brand: Burndy
|
SKU:
10668497
Regular price
$18.45
Unit price
Description
Description
Burndy YAV35M10 | Compression Terminal
Non insulated Cu tubular terminals, Metric, 1 Hole/W/insp W, 35mm, M10 stud, Tin - Electro Plated, 10 Index.
Burndy - YAV35M10 - Features
- Barrel is designed with an internal chamfer at the wire entry to ensure smooth insertion of the wire, preventing possible damaging of the strands
- Electro-tin plated unless otherwise specified to reduce galvanic corrosion (bimetallic) and resist corrosive
- Compatible Standards: IEC61238-1, UL 486A-486B, CSA-C22.2 No. 65-03
Specifications
Specifications
Burndy - YAV35M10 - Specifications
| Application | Metric Wire Termination |
|---|---|
| Catalog Number | YAV35M10 |
| Color Code | Brown |
| Connector Type | METRIC |
| Construction Material - Main | Copper tubing |
| Die Index | 10 |
| Feature - Barrel Style | Chamfered |
| Finish Type | Tin-Plated |
| Material | Copper |
| Number of Pad Holes | 1 |
| Physical Attribute - Number of Holes | 1 |
| Plated | Yes |
| Plating Type | Tin |
| Sub Brand | Terminals, HYLUG |
| Temperature Rating | 194 |
| Trade Name | HYLUG™ |
| Type | Metric Terminals |
| UPC | 781810294185 |
| UPC 14 Digit GTIN | 00781810294185 |
