Brand: Burndy
|
SKU:
1054223
Burndy YAZ262TC38E16 | Compression Terminal, 2/0 AWG Copper, 2-Hole, 3/8 in. Stud, 1-3/4 in. Spacing, Long Barrel
Regular price
$24.85
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Burndy YAZ262TC38E16 | Compression Terminal, 2/0 AWG Copper, 2-Hole...
Regular price
$24.85
Unit price
Description
Description
Burndy YAZ262TC38E16 | Compression Terminal, 2/0 AWG Copper, 2-Hole, 3/8 in. Stud, 1-3/4 in. Spacing, Long Barrel
2/0 AWG CU, Two Hole, 3/8 Stud Size, 1-3/4 Hole Spacing, Long Barrel, Inspection Window Internal Chamfer, Tin Plated, UL/CSA, 90°C, Up to 35kV, Black Color Code, 13 Die Index.
Burndy - YAZ262TC38E16 - Features
- Barrel is designed with an internal chamfer at the wire entry to ensure smooth insertion of the wire, preventing possible damaging of the strands
- Electro-tin plated unless otherwise specified to reduce galvanic corrosion (bimetallic) and resist corrosive elements
- Connectors are clearly marked with stamping and barrel color coding
Specifications
Specifications
Burndy - YAZ262TC38E16 - Specifications
| Application | Wire Termination |
|---|---|
| Catalog Number | YAZ262TC38E16 |
| Color Code | Black |
| Connector Type | LONG BARREL |
| Die Index | 13 |
| Feature - Barrel Style | Skived |
| Feature - Barrel Type | Long |
| Finish Type | Tin-Plated |
| Material | Copper |
| Number of Pad Holes | 2 |
| Plated | Yes |
| Plating Type | Tin |
| Trade Name | HYLUG™ |
| Type | Long Barrel, Skive, Tin Plated |
| UPC | 781810563472 |
| UPC 14 Digit GTIN | 00781810563472 |
