Burndy YAZ4C2TC1445 | 25019279 | Hylug Copper Tubing Compression Lug, 2 Hole with Inspection Window, 4 AWG Code

Burndy - YAZ4C2TC1445 | 25019279 - Features

• Internally beveled barrel end for easy cable insertion, connector clearly marked with wire size and type, die index and color coding, markings provide for inspectability along with ease of determining proper tooling recommended.
• Tubing Compression Lug
• Tongue Angle: 45 Degree
• Length: 2.48 Inch
• Tongue Type: Standard
• Barrel Style: Skived
• Bolt Hole Size: 0.27 Inch
• Stud Size: 1/4 Inch
• B
• Length: 1.12 Inch
• Pad Width: 0.5 InchHole to Hole Distance: 0.62 Inch
• Strip
• Number Of Holes: 2
• Wire Size: 4 AWG Code And 40 Navy
• Type Of Plating: Electro Plated Tin
• Color Code: Gray
• Index Number: 8, 346
• Material: Copper
• Voltage Rating: 600 Volt - 35 Kilo-Volt
