Burndy YAZ6C2TC1490 | 25019256 | Copper Compression Terminal, Bevel Entry, 2 Holes with Inspection Window

Burndy - YAZ6C2TC1490 | 25019256 - Features

• Internally beveled barrel end for easy cable insertion, connector clearly marked with wire size and type, die index and color coding, markings provide for inspectability along with ease of determining proper tooling recommended.
• Compression Terminal
• Tongue Angle: 90 Degree
• Length: 1.51 Inch
• Tongue Type: Standard
• Barrel Style: Skived
• Bolt Hole Size: 0.27 Inch
• Stud Size: 1/4 Inch
• B
• Length: 1.12 Inch
• Pad Width: 0.45 InchHole to Hole Distance: 0.62 Inch
• Strip
• Number Of Holes: 2
• Wire Size: 6 AWG Copper Stranded, 30 AWG (19) Navy
• Type Of Plating: Electro Plated Tin
• Color Code: Blue
• Index Number: 7, 374
• Material: Copper
• Voltage Rating: 600 Volt - 35 Kilo-Volt
