Brand: Burndy
|
SKU:
YGA252N
Burndy YGA252N | Compression Ground Lug, 1/0 AWG Copper, 2-Hole NEMA Pad
Regular price
$43.48
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Burndy YGA252N | Compression Ground Lug, 1/0 AWG Copper, 2-Hole NEM...
Regular price
$43.48
Unit price
Description
Description
Burndy YGA252N | Compression Ground Lug, 1/0 AWG Copper, 2-Hole NEMA Pad
HYGROUND® Grounding Irreversible Compression Terminal: 2-Hole with Inspection Window; Accommodates: 1/0 AWG; 1/2" Stud; 1-3/4" Spacing.
Burndy - YGA252N - Features
- Irreversible Compression Grounding Lug
- Inspection port to ensure proper cable insertion
- UL 467 Listed, Acceptable for direct burial in earth or concrete
- Prefilled with PENETROX Oxide Inhibiting Compound and strip sealed
- 2 Stud Holes, 1-3/4" Spacing
- Run: 1/0 Str Copper
- Die Index 12
Specifications
Specifications
Burndy - YGA252N - Specifications
| Application | Irreversible compression HYLUG ground terminal specifically designed for grounding applications |
|---|---|
| Catalog Number | YGA252N |
| Color Code | Pink |
| Connector Type | Terminal |
| Construction Material - Main | Copper |
| Die Index | 12;348 |
| Material | Copper |
| Physical Attribute - Number of Crimps Required | 2 |
| Plated | No |
| Plating Type | Unplated |
| Sub Brand | HYLUG |
| Trade Name | HYLUG™ |
| Type | Terminals |
| UPC | 781810220627 |
| UPC 14 Digit GTIN | 00781810220627 |
