C2G C2G50348 | AV Controller
Description
Description
The AV Controller is a full-featured in-wall solution that is perfect for easy control of all classroom or conference room audio/video equipment; including up to two serial devices, such as a projector or display, a 12V DC triggered device, such as a projector screen or blinds and IR devices such as a DVD/Blu-ray player, document camera and other equipment. Specifically constructed for use in classrooms and conference rooms, this controller is innovatively simple to install, program and operate.
Consolidate control in one convenient location. No more searching for remotes, replacing expensive batteries or fumbling with small remote keys that are in a different position on each different remote. The AV Controller provides the features needed without the cost and complexity associated with "higher end" solutions.
C2G - C2G50348 - Features
- Eight backlit buttons with multiple button options
- On-board timing program making it easy to perform time and date programming
- Dual DB9 RS-232 as well as RS-485 ports provides control of up to five devices
- All buttons can be programmed to send the bi-direction infrared, RS232 and RS485 commands simultaneously to control third party devices
- Daisy chain up to 99 controllers
Specifications
Specifications
C2G - C2G50348 - Product Categories
- Audio and Visual
- AV Control and Monitoring Systems
- Media Controllers
C2G - C2G50348 - Specifications
| Manufacturer Part Number | C2G50348 |
|---|---|
| Brand Name | C2G (Legrand) |
| Color | White |
| Type | Accessory, Active Device, Controller |
| Application Sector | Commercial |
| Product Line | C2G |
| Country Of Origin | China |
| Features | RS232 |
| Warranty Type | 5-Year |
| UPC Number | 757120503484 |
| Product Depth US | 1.11 in |
| Product Height US | 4.5 in |
| Product Width US | 2.75 in |
| FCC Compliant | Yes |
| Input Voltage | 100 to 240 V |
| Operating Humidity | 10-90% RH |
| Storage Humidity | 10-90% RH (Non-Condensing) |
| Output Voltage | 12 VDC |
| UNSPSC Code | 46171600 |
