Chief Manufacturing CMA347 | Vibration Isolating Coupler
Regular price
$401.24
Unit price
Brand: Chief Manufacturing
|
SKU:
853848
Regular price
$401.24
Unit price
Description
Description
Chief Manufacturing CMA347 | Vibration Isolating Coupler
Chief Manufacturing CMA347 reduces projector image movement due to building vibration. The CMA347 is the only true vibration dampening accessory on the market today. It is a unique design that soaks up vibration above the mount connection point. Can be used with any 1 1/2 inch NPT extension columns and includes two sets of springs for different weight mounting options.
Chief Manufacturing - CMA347 - Features
- Connects two extension columns and isolates vibration transmitted to lower column
- Patented design isolates vibration to reduce image movement
- Tech Info
- CAVSP, CEDIA, NSCA, AIA
- Vibration Mount
- Reduces projector image movement due to building vibration
- Can be used with any 1 1/2 in. NPT extension columns
- Includes two sets of springs for different weight mounting options
- Connects two extension columns and isolates vibration transmitted to lower column
- Patented design isolates vibration to reduce image movement
- 35 lbs weight capacity
Specifications
Specifications
Chief Manufacturing - CMA347 - Specifications
| Manufacturer | Chief Manufacturing |
|---|---|
| Manufacturer Part Number | CMA-347 |
| Manufacturer Website Address | www.chiefmfg.com |
| Brand Name | Chief |
| Product Series | CMA |
| Product Model | CMA-347 |
| Product Name | CMA-347 Vibration Mount |
| Product Type | Surface Mount |
| Load Capacity | 35 lb Maximum |
| Material | Steel |
| Package Contents | CMA-347 Vibration Mount Includes: 1 x CMA-347 Top 1 x CMA-347 Bottom 3 x WEIGHT, 2.5 Pound 3 x DAMPER, Sorbothane, Stepped 12 x DAMPER, Sorbothane 15 x WASHER, Flat, 1/4" 6 x SPRING, Small 3 x SPRING, Long Medium Gauge 3 x SPRING, Long Heavy Gauge 6 x BUSHING, Vibration, Stepped 3 x NUT, Nylock, 1/4-20 3 x BOLT, Hex Tap, (1/4-20 x 4") 3 x WASHER, Fender, 1" OD 3 x NUT,Nylock, 3/8-16 3 x SCREW, Cap, Hex Head, (3/8-16 x 1.5") 2 x SCREW, Set, Socket Head, (5/16-18 x 3/8") 1 x KEY, Hex, 5/32" |
| Compatibility | Projector |
| UNSPSC Code | 45111800 |
