CMP Products CG-150A149 | Cord Grip, Aluminum Body, 1-1/2 in., 1.22 in., 1.49 in., Straight, NPT Thread
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
CMP Products CG-150A149 | Cord Grip, Aluminum Body, 1-1/2 in., 1.22...
Description
Description
The CG Series cable connector is cULus-listed to the latest editions of UL-514B and CSA 22.2 No. 18.3-12, for use with all types of flexible cables and cords for installations in accordance with the NEC compliant and CEC compliant. Its wide sealing range reduces the need for multiple connector sizes to cover a varied range of cables. The CG Series is supplied complete with an entry thread seal and locknut. The product has an operational temperature range of -76 to 194 F and if additional cable support or retention is required, the CG Series can easily accommodate a strain relief, making the CMP CG Series suitable for use in many harsh and corrosive environments.
Specifications
Specifications
CMP Products - CG-150A149 - Product Categories
- Electrical Supplies and Lighting
- Electrical Supplies
- Electrical Connectors
- Cord Grips
CMP Products - CG-150A149 - Specifications
| Manufacturer Name | CMP Products |
|---|---|
| Manufacturer Part Number | CG-150A149 |
| Item Description | Cord Grip, Aluminum Body, 1-1/2 in., 1.22 in., 1.49 in., Straight, NPT Thread |
| Body Material | Aluminum |
| Cable Outside Diameter Maximum | 1.49 in. |
| Cable Outside Diameter Minimum | 1.22 in. |
| Connector Angle | Straight |
| Hub Size | 1-1/2 in. |
| Product Type | Cord Grip |
| Special Rating | Wet or Hazardous Location, IP66, IP67, IP68, NEMA 4X, 6P |
| Thread Type | NPT |
