CommScope 143SEM | Fixed-Tuned PDR48 for Elliptical Waveguide
Regular price
$650.83
Unit price
Brand: CommScope
|
SKU:
464018
Regular price
$650.83
Unit price
Description
Description
CommScope 143SEM | Fixed-Tuned PDR48 for Elliptical Waveguide
Specifications
Specifications
Product Classification
| Product Type | Elliptical waveguide connector |
|---|
General Specifications
| Attachment Method | Tab-flare / Tool-flare |
|---|---|
| Body Style | Straight, fixed-tuned |
| Inner Contact Plating | Unplated |
| Interface | PDR48 |
| Outer Contact Plating | Unplated |
| Pressurizable | Yes |
Dimensions
| Width | 116.84 mm / 4.6 in |
|---|---|
| Length | 145.288 mm / 5.72 in |
| Transition Length | 91.694 mm / 3.61 in |
| Waveguide Size | WR187 / WG12 / R48 |
Electrical Specifications
| Insertion Loss, typical | 0.01 dB |
|---|---|
| Operating Frequency Band | 4.4 – 5.0 GHz |
| Peak Power at Frequency, maximum | 187.00 kW @ 4.70 GHz |
Material Specifications
| Material Type | Brass |
|---|
Environmental Specifications
| Operating Temperature | -55 °C to +85 °C (-67 °F to +185 °F) |
|---|---|
| Storage Temperature | -55 °C to +85 °C (-67 °F to +185 °F) |
Packaging and Weights
| Weight, net | 3.4 kg / 7.496 lb |
|---|
Regulatory Compliance/Certifications
| ISO 9001:2015 | Designed, manufactured and/or distributed under this quality management system |
|---|---|
| ROHS | Compliant |
| CHINA-ROHS | Below maximum concentration value |
| REACH-SVHC | Compliant as per SVHC revision on www.commscope.com/ProductCompliance |
