CommScope 163SE | Fixed-tuned CPR137G for elliptical waveguide 63
Regular price
$383.90
Unit price
Brand: CommScope
|
SKU:
10404316
Regular price
$383.90
Unit price
Description
Description
CommScope 163SE | Fixed-tuned CPR137G for elliptical waveguide 63
Specifications
Specifications
CommScope - 163SE - Product Categories
- Connectors
- Elliptical Waveguide Connectors
CommScope - 163SE - Product Classification
| Product Type | Elliptical waveguide connector |
|---|
CommScope - 163SE - General Specifications
| Brand Name | CommScope |
|---|---|
| Item Description | Fixed-tuned CPR137G for elliptical waveguide 63 |
| Model Number | 163SE |
| Attachment Method | Tab-flare | Tool-flare |
| Body Style | Straight, fixed-tuned |
| Inner Contact Plating | Unplated |
| Interface | CPR137G |
| Outer Contact Plating | Unplated |
| Pressurizable | Yes |
CommScope - 163SE - Additional Information
| Dimensions | - |
|---|---|
| Width | 85.852 mm | 3.38 in |
| Length | 85.344 mm | 3.36 in |
| Transition Length | 52.832 mm | 2.08 in |
| Waveguide Size | WR137 | WG14 | R70 |
| Electrical Specifications | - |
| Insertion Loss, typical | 0.01 dB |
| Operating Frequency Band | 5.725 – 7.125 GHz |
| Peak Power at Frequency, maximum | 102.00 kW @ 6.78 GHz |
| Material Specifications | - |
| Material Type | Brass |
| Environmental Specifications | - |
| Operating Temperature | -55 °C to +85 °C (-67 °F to +185 °F) |
| Storage Temperature | -55 °C to +85 °C (-67 °F to +185 °F) |
