Commscope 209821 | Angle Adapter, compact 1/4 in tapped hole
Regular price
$34.43
Unit price
Brand: CommScope
|
SKU:
463910
Regular price
$34.43
Unit price
Description
Description
Commscope 209821 | Angle Adapter, compact 1/4 in tapped hole
Specifications
Specifications
Product Classification
| Product Type | Adapter |
|---|---|
| Ordering Note | CommScope non-standard product |
General Specifications
| Adapter Type | Angle adapter |
|---|---|
| Mounting | 1/4 in tapped hole |
Dimensions
| Inside Width | 16.51 mm / 0.65 in |
|---|---|
| Outside Width | 21.59 mm / 0.85 in |
| Inside Length | 16.002 mm / 0.63 in |
| Outside Length | 44.45 mm / 1.75 in |
| Material Thickness | 2.337 mm / 0.092 in |
Material Specifications
| Material Type | Zinc-plated steel |
|---|
Mechanical Specifications
| Installation Torque, maximum | 16.27 N-m / 12 ft lb |
|---|---|
| Installation Torque, minimum | 13.558 N-m / 10 ft lb |
| Maximum Loading | Single, 1-5/8 in cable |
Packaging and Weights
| Height, packed | 2.5 cm / 0.984 in |
|---|---|
| Width, packed | 12.7 cm / 5 in |
| Length, packed | 20.3 cm / 7.992 in |
| Packaging quantity | 10 |
| Weight, gross | 0.69 kg / 1.521 lb |
Regulatory Compliance/Certifications
| ISO 9001:2015 | Designed, manufactured and/or distributed under this quality management system |
|---|---|
| ROHS | Compliant |
| REACH-SVHC | Compliant as per SVHC revision on www.commscope.com/ProductCompliance |
