Commscope 240PDF-BHC-CR | 7-16 Din Female Bulkhead For Cnt-240 Braided Cable

Commscope - 240PDF-BHC-CR - Product Categories

• Communications
• Coaxial Cabling Infrastructure
• Coaxial Connectors

Commscope - 240PDF-BHC-CR - Additional Information

• Female Bulkhead Connector
• Type: 7-16 DIN Female
• Operating Frequency Band: 0 - 6000 MHz
• Insertion Loss (Typical): 0.05 dB
• Connector Retention Torque: 0.23 N-m (0.17 ft lb)
• Nominal Size: 0.240 Inch
• Inner Contact Resistance (Maximum): 0.40 mOhm
• VSWR: 1.07 - 1.12
• Outer Contact Resistance (Maximum): 1.50 mOhm
• Average Power Inner Conductor Temperature: 100 deg C (212 deg F)
• Insulation Resistance (Minimum): 10000 mOhm
• Connector Retention Tensile Force: 134 N (30 lbf)
• DC Test Voltage: 1500 Volt
• Attenuation Ambient Temperature: 20 deg C (68 deg F)
• Return Loss: 30.00 - 25.00 dB
• Average Power Ambient Temperature: 40 deg C (104 deg F)
• Operating Temperature: -40 to 85 deg C (-40 to 185 deg F)
• Diameter: 41 mm (1.61 Inch)
• Width: 41 mm (1.61 Inch)
• Length: 44.80 mm (1.76 Inch)
• Peak Power Maximum: 5.60 kW
• Cable Impedance: 50 Ohm
• Connector Impedance: 50 Ohm
• Interface Durability: 500 Cycles
• RF Operating Voltage (Maximum, VRMS): 529 Volt
• Storage Temperature: -65 to 125 deg C (-85 to 257 deg F)
• Interface: 7-16 DIN Female
• Body Style: Bulkhead
• Inner Contact Attachment Method: Captivated
• Outer Contact Attachment Method: Crimp
• Water Jetting Test Mating: Mated
• Inner Contact Plating: Silver
• Outer Contact Plating: Trimetal

Commscope - 240PDF-BHC-CR - Specifications

• Commscope 240PDF-BHC-CR Specification Sheet
