CommScope 3071E WHT C6 | Cable, 23 Awg, 4 Pair, Unshielded Twisted ...
Description
Description
The SYSTIMAX 71E series GigaSPEED XL cable transmits reliable voice, data and video, with excellent quality of service.The 71E series GigaSPEED XL family of unshielded twisted pair cables includes the 1071E non-plenum, 2071E plenum, and 3071E low smo ke zero-halogen (LSZH) cables. These cables feature bi-sector tape that delivers the performance benefits of more traditional fluted center members, without the associated stiffness and size. Combine this with the GigaSPEED XL apparatus, for the ultima te in cabling system performance.
Key Features
- 4-pair U/UTP construction with patented bi-sector separator tape provides the added performance margin required to support high bandwidth applications at an economical price
- Can support network line speeds in excess of 1 gigabit per second
- Qualifies for a 20-year product and applications assurance warranty when included as part of a certified SYSTIMAX GigaSPEED XL channel
Specifications
Specifications
Specification Description
- U/UTP Cable
- Jacket Material: Low Smoke Zero Halogen
- Conductor Material: Bare Copper
- Insulation Material: Polyolefin
- Separator Material: Polyolefin
- Cable Length: 305 m (1000 ft)
- Diameter Over Jacket: 0.233 Inch (5.918 mm)
- Jacket Thickness: 0.020 Inch (0.508 mm)
- DC Resistance Unbalance: 5% Maximum
- DC Resistance: 7.61 Ohm/100 m Maximum
- Mutual Capacitance: 5.6 nF/100 m At 1 kHz
- Nominal Velocity Of Propagation: 69%
- Operating Frequency: 300 MHz Maximum
- Operating Voltage: 80 Volt Maximum
- Environmental Space: Low Smoke Zero Halogen (LSZH)
- Installation Temperature: 32 to 140 deg F (0 to 60 deg C)
- Operating Temperature: -4 to 140 deg F (-20 to 60 deg C)
- Pair Quantity: 4
- Cable Component Type: Horizontal
- Jacket Color: White
- Product Number: 3071E
- Conductor Gauge: 23 AWG (Singles)
- Conductor Type: Solid (Singles)
- Conductor Quantity: 8
- Separator Type: Bisector
- Pulling Tension: 25 lb (11 kg) Maximum
Specifications
| Category | CATEGORY 6 |
|---|---|
| Conductor Size | 23 AWG (AMERICAN WIRE GAUGE) |
| Conductor Type | SOLID |
| Conductor/Pair Count | 4 PAIR |
| Fire Rating | LOW SMOKE ZERO HALOGEN (LSZH) |
| Jacket Color | WHITE |
| Shielded | U/UTP - UNSHIELDED TWISTED PAIR |
| Type | DATA |
| UNSPSC Code | 26121609 |
