Brand: CommScope
|
SKU:
CMP00424X10DFTP-10-6
CommScope 760122630 | Utp Cable, Plenum, 23 Awg (Conductor),24 Awg (Drain Wire), Cat 6A, 4-Pair, 8-Conductor, 0.276" Cable Diameter, 1000’ Length, 80 Volt
Regular price
$3.00
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
CommScope 760122630 | Utp Cable, Plenum, 23 Awg (Conductor),24 Awg ...
Regular price
$3.00
Unit price
Brand: CommScope
|
SKU:
CMP00424X10DFTP-10-6
Regular price
$3.00
Unit price
Shipping calculated at checkout.
Description
Description
CommScope 760122630 | Utp Cable, Plenum, 23 Awg (Conductor),24 Awg (Drain Wire), Cat 6A, 4-Pair, 8-Conductor, 0.276" Cable Diameter, 1000’ Length, 80 Volt
Specifications
Specifications
CommScope - 760122630 - Product Categories
- Communications
- Copper Cabling Infrastructure
- Voice and Data Cable
- Cables
- Twisted Pair Cables
- Category 6A Cables
CommScope - 760122630 - Additional Information
- Technical Information:
- ISO 9001:2008, ETL
CommScope - 760122630 - General Specifications
| Product Classification | - |
|---|---|
| Regional Availability | Asia | Australia/New Zealand | EMEA | Latin America | North America |
| Portfolio | SYSTIMAX |
| Product Type | Twisted pair cable |
| General Specifications | - |
| Product Number | 2291B |
| ANSI/TIA Category | 6A |
| Cable Component Type | Horizontal |
| Cable Type | F/UTP (shielded) |
| Conductor Type, singles | Solid |
| Conductors, quantity | 8 |
| Drain Wire Type | Solid |
| Jacket Color | Blue |
| Pairs, quantity | 4 |
| Separator Type | Isolator |
| Transmission Standards | ANSI/TIA-568.2-D |
| Dimensions | - |
| Cable Length | 304.8 m | 1000 ft |
| Diameter Over Jacket, nominal | 7.01 mm | 0.276 in |
| Jacket Thickness | 0.457 mm | 0.018 in |
| Conductor Gauge, singles | 23 AWG |
| Drain Wire Gauge | 26 AWG |
| Electrical Specifications | - |
| DC Resistance Unbalance, maximum | 4 % |
| DC Resistance, maximum | 8 ohms/100 m | 2.438 ohms/100 ft |
| Dielectric Strength, minimum | 1500 Vac | 2500 Vdc |
| LP (Limited Power) Rating | 0.8 A |
| Mutual Capacitance at Frequency | 5.6 nF/100 m @ 1 kHz |
| Nominal Velocity of Propagation (NVP) | 70 % |
| Operating Frequency, maximum | 500 MHz |
| Operating Voltage, maximum | 80 V |
| Remote Powering | Fully complies with the recommendations set forth by IEEE 802.3bt (Type 4) for the safe delivery of power over LAN cable when installed according to ISO/IEC 14763-2, CENELEC EN 50174-1, CENELEC EN 50174-2 or TIA TSB-184-A |
| Mechanical Specifications | - |
| Installation temperature | 0 °C to +60 °C (+32 °F to +140 °F) |
| Operating Temperature | -20 °C to +60 °C (-4 °F to +140 °F) |
| Environmental Space | Plenum |
| Temperature Rating, ETL | 105 °C | 221 °F |
| Environmental Specifications | - |
| Cable weight,Packaging Type | 58.038 kg/km | 39 lb/kft,Reel |
| Packaging and Weights | - |
| ISO 9001:2015 | Designed, manufactured and/or distributed under this quality management system |
| ROHS | Compliant |
| CHINA-ROHS | Below maximum concentration value |
| REACH-SVHC | Compliant as per SVHC revision on www.commscope.com/ProductCompliance |
| UK-ROHS | Compliant |
CommScope - 760122630 - Specifications
| Brand Name | CommScope |
|---|---|
| Manufacturer Part Number | 760122630 |
| Item Description | Utp Cable, Plenum, 23 Awg (Conductor),24 Awg (Drain Wire), Cat 6A, 4-Pair, 8-Conductor, 0.276" Cable Diameter, 1000’ Length, 80 Volt |
| Category | Category 6A |
| Conductor Size | 23 Awg (American Wire Gauge) |
| Conductor Type | Solid |
| Conductor/Pair Count | 4 Pair |
| Fire Rating | Plenum |
| Jacket Color | Blue |
| Shielded | F/Utp - Foiled/Unshielded Twisted Pair |
| Type | Data |
| UNSPSC Code | 26121609 |
