Brand: CommScope
|
SKU:
CMZ-00423COM-C6R-05
CommScope 760177410 | GigaSPEED XL 5071A ETL Verified Category 6 U/UTP Cable, LSZH, non-plenum CMR rated, yellow jacket, 4 pair count, 3000 ft (914 m) length, reel
Regular price
$1.46
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
CommScope 760177410 | GigaSPEED XL 5071A ETL Verified Category 6 U/...
Regular price
$1.46
Unit price
Brand: CommScope
|
SKU:
CMZ-00423COM-C6R-05
Regular price
$1.46
Unit price
Shipping calculated at checkout.
Description
Description
CommScope 760177410 | GigaSPEED XL 5071A ETL Verified Category 6 U/UTP Cable, LSZH, non-plenum CMR rated, yellow jacket, 4 pair count, 3000 ft (914 m) length, reel
Specifications
Specifications
CommScope - 760177410 - Product Categories
- Cables
- Twisted Pair Cables
- Category 6 Cables
CommScope - 760177410 - Product Classification
| Regional Availability | Asia | Australia/New Zealand | EMEA | Latin America | North America |
|---|---|
| Portfolio | SYSTIMAX |
| Product Type | Twisted pair cable |
| Product Brand | GigaSPEED XL |
CommScope - 760177410 - General Specifications
| Brand Name | CommScope |
|---|---|
| Item Description | GigaSPEED XL 5071A ETL Verified Category 6 U/UTP Cable, LSZH, non-plenum CMR rated, yellow jacket, 4 pair count, 3000 ft (914 m) length, reel |
| Model Number | 760177410 | 5071A YEL C6 4/23 U/UTP R3000 |
| Product Number | 5071A |
| ANSI/TIA Category | 6 |
| Cable Component Type | Horizontal |
| Cable Type | U/UTP (unshielded) |
| Conductor Type, singles | Solid |
| Conductors, quantity | 8 |
| Jacket Color | Yellow |
| Note | A maximum recommended horizontal cable length is 70 meters (230 feet) for a 75C environment | Elevated temperatures may require cable length derating per ANSI/TIA 568-C.2 Annex G to ensure channel insertion loss compliance |
| Pairs, quantity | 4 |
| Separator Type | Bisector |
| Transmission Standards | ANSI/TIA-568.2-D | CENELEC EN 50288-6-1 | ISO/IEC 11801 Class E |
CommScope - 760177410 - Additional Information
| Dimensions | - |
|---|---|
| Cable Length | 914.4 m | 3000 ft |
| Diameter Over Jacket, nominal | 6.096 mm | 0.24 in |
| Jacket Thickness | 0.635 mm | 0.025 in |
| Conductor Gauge, singles | 23 AWG |
| Electrical Specifications | - |
| dc Resistance Unbalance, maximum | 0.05 |
| dc Resistance, maximum | 7.61 ohms/100 m | 2.32 ohms/100 ft |
| Dielectric Strength, minimum | 1500 Vac | 2500 Vdc |
| Mutual Capacitance at Frequency | 5.6 nF/100 m @ 1 kHz |
| Nominal Velocity of Propagation (NVP) | 0.69 |
| Operating Frequency, maximum | 300 MHz |
| Operating Voltage, maximum | 80 V |
| Remote Powering | Fully complies with the recommendations set forth by IEEE 802.3bt (Type 4) for the safe delivery of power over LAN cable when installed according to ISO/IEC 14763-2, CENELEC EN 50174-1, CENELEC EN 50174-2 or TIA TSB-184-A |
| Material Specifications | - |
| Conductor Material | Bare copper |
| Insulation Material | Polyolefin |
| Jacket Material | Low Smoke Zero Halogen (LSZH) |
| Separator Material | Polyolefin |
| Mechanical Specifications | - |
| Pulling Tension, maximum | 11.34 kg | 25 lb |
