CommScope 760249555 | Field Term Modular Plug, RJ45, Cat6A, Large Wire
Regular price
$679.49
Unit price
Brand: CommScope
|
SKU:
10331842
Regular price
$679.49
Unit price
Description
Description
CommScope 760249555 | Field Term Modular Plug, RJ45, Cat6A, Large Wire
Specifications
Specifications
CommScope - 760249555 - Specifications
| Regional Availability | Asia | Australia/New Zealand | EMEA | Latin America | North America |
|---|---|
| Portfolio | CommScope® |
| Product Type | Modular plug |
| ANSI/TIA Category | 6A |
| Cable Type | U/UTP (unshielded) |
| Color | Clear |
| Conductor Type | Solid | Stranded |
| Interface | RJ45 |
| Positions/Loaded Contacts | 8 |
| Termination Type | IDC |
| Compatible Cable Diameter, maximum | 7.3 mm | 0.287 in |
| Compatible Cable Diameter, minimum | 7.1 mm | 0.280 in |
| Compatible Insulated Conductor Diameter, maximum | 1.03 mm | 0.041 in |
| Compatible Insulated Conductor Diameter, minimum | 0.9 mm | 0.035 in |
| Contact Plating Thickness | 1.27 µm |
| Compatible Conductor Gauge, solid | 23 AWG | 24 AWG |
| Plug Insertion Life, minimum | 750 times |
| Packaging quantity | 100 |
| Packaging Type | Bag |
| ROHS | Compliant |
| CHINA-ROHS | Below maximum concentration value |
