Brand: CommScope
|
SKU:
621666
Commscope CMAX-D-CPUSEI53 | Low PIM Directional In-building Antenna, 698–960 MHz, 1710–2700 MHz
Regular price
$124.53
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Commscope CMAX-D-CPUSEI53 | Low PIM Directional In-building Antenna...
Regular price
$124.53
Unit price
Description
Description
Commscope CMAX-D-CPUSEI53 | Low PIM Directional In-building Antenna, 698–960 MHz, 1710–2700 MHz
Specifications
Specifications
Outline Drawing
| Click on image to enlarge. |
|---|
Product Classification
| Product Type | In-building antenna |
|---|
General Specifications
| Application | Indoor |
|---|---|
| Antenna Type | Directional |
| Polarization | Vertical |
| Color | White |
| Mounting | 4-hole wall mounting plate and hardware (included) |
| Number of Ports | 1 |
| Pigtail Cable | 670-141SXE, plenum rated |
| Radome Material | ABS |
| RF Connector Interface | N Female |
Dimensions
| Width | 180 mm / 7.087 in |
|---|---|
| Depth | 62 mm / 2.441 in |
| Length | 262 mm / 10.315 in |
| Pigtail Length | 420 mm / 16.535 in |
Electrical Specifications
| Electrical Note | PIM specifications are less than or equal to the stated value |
|---|---|
| Impedance | 50 ohm |
| Operating Frequency Band | 698 – 960 MHz / 1710 – 2700 MHz |
Environmental Specifications
| Operating Temperature | -40 °C to +60 °C (-40 °F to +140 °F) |
|---|---|
| Relative Humidity | Up to 100% |
Packaging and Weights
| Width, packed | 185 mm / 7.283 in |
|---|---|
| Depth, packed | 85 mm / 3.346 in |
| Length, packed | 320 mm / 12.598 in |
| Packaging quantity | 1 |
| Weight, gross | 1 kg / 2.205 lb |
| Weight, net | 0.9 kg / 1.984 lb |
Regulatory Compliance/Certifications
| ISO 9001:2015 | Designed, manufactured and/or distributed under this quality management system |
|---|
Documents and Downloads
Documents and Downloads
- Installation Guide for CMAX-D-43-UW-i53/CMAX-D-UW-i53/CMAX-D-TCPUSEi53 Antennas
- M0149ARA Installation Guide for CMAX-D-43-UW-i53/CMAX-D-UW-i53/CMAX-D-TCPUSEi53 Antennas
- Statement of Compliance RoHS/REACH
- CMAX-D-CPUSEI53 Product specifications
- Customer and Technical Support, Training, Software/Firmware, Repair Services
- CommScope Limited Product Warranty
