Brand: CommScope
|
SKU:
621672
Commscope CMAXEXTCPUSEI53 | Cell-Max Low PIM Directional Outdoor Antenna, 698–960 MHz and 1710–2700 MHz
Regular price
$570.81
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Commscope CMAXEXTCPUSEI53 | Cell-Max Low PIM Directional Outdoor An...
Regular price
$570.81
Unit price
Description
Description
Commscope CMAXEXTCPUSEI53 | Cell-Max Low PIM Directional Outdoor Antenna, 698–960 MHz and 1710–2700 MHz
Specifications
Specifications
Outline Drawing
| Click on image to enlarge. |
|---|
Product Classification
| Product Type | Over-the-head stadium antenna |
|---|---|
| Product Brand | Cell-Max |
General Specifications
| Application | Indoor/Outdoor |
|---|---|
| Antenna Type | Directional |
| Antenna Array Characteristic | SISO |
| Polarization | Vertical |
| Color | White (RAL 9016) |
| Mounting | Poles between 25–60 mm with supplied clamps |
| Number of Ports | 1 |
| Radome Material | PVC, UV resistant |
| RF Connector Interface | 7-16 DIN Female |
Dimensions
| Width | 331 mm / 13.032 in |
|---|---|
| Depth | 98 mm / 3.858 in |
| Length | 620 mm / 24.409 in |
Electrical Specifications
| Impedance | 50 ohm |
|---|---|
| Lightning Protection | dc Ground |
| Operating Frequency Band | 698 – 960 MHz / 1710 – 2700 MHz |
Mechanical Specifications
| Wind Loading at Velocity, maximum | 154.2 lbf/216 km/h / 686.0 N/216 km/h |
|---|---|
| Wind Speed, maximum | 216 km/h / 134.216 mph |
Environmental Specifications
| Operating Temperature | -40 °C to +60 °C (-40 °F to +140 °F) |
|---|---|
| Relative Humidity | Up to 100% |
| Ingress Protection Test Method | IEC 60529:2001, IP65 |
Packaging and Weights
| Width, packed | 350 mm / 13.78 in |
|---|---|
| Depth, packed | 160 mm / 6.299 in |
| Length, packed | 830 mm / 32.677 in |
| Packaging quantity | 1 |
| Weight, gross | 7.4 kg / 16.314 lb |
| Weight, net | 4.7 kg / 10.362 lb |
Regulatory Compliance/Certifications
| ISO 9001:2015 | Designed, manufactured and/or distributed under this quality management system |
|---|---|
| ROHS | Compliant |
| CHINA-ROHS | Below maximum concentration value |
| REACH-SVHC | Compliant as per SVHC revision on www.commscope.com/ProductCompliance |
