Brand: CommScope | SKU: 1042514

Commscope CMAXOMFCPUSEI53 | Cell-Max Low PIM Omni MIMO In-building Antenna, 698–960 MHz and 1710–2700 MHz

$235.68

Shipping calculated at checkout.

Low prices.

Price match guarantee
In-House Experts.

We know our products
Easy Returns.

Quick & Hassle Free
Superior Selection.

Extensive product catalog

Description

Commscope CMAXOMFCPUSEI53 | Cell-Max Low PIM Omni MIMO In-building Antenna, 698–960 MHz and 1710–2700 MHz

Specifications

Outline Drawing

Click on image to enlarge.

Product Classification

Product Type	In-building antenna
Product Brand	Cell-Max

General Specifications

Application	Indoor
Antenna Type	Omni
Polarization	Horizontal / Vertical
Color	White
Mounting	Thru-hole ceiling mount (optional)
Number of Ports	2
Pigtail Cable	670-141SXE, plenum rated
Radome Material	ABS
RF Connector Interface	N Female

Dimensions

Height	151 mm / 5.945 in
Pigtail Length	500 mm / 19.685 in
Outer Diameter	220 mm / 8.661 in

Electrical Specifications

Impedance	50 ohm
Operating Frequency Band	698 – 960 MHz / 1710 – 2700 MHz

Environmental Specifications

Operating Temperature	-40 °C to +60 °C (-40 °F to +140 °F)
Relative Humidity	Up to 100%

Packaging and Weights

Height, packed	215 mm / 8.465 in
Width, packed	215 mm / 8.465 in
Length, packed	215 mm / 8.465 in
Weight, gross	0.9 kg / 1.984 lb
Weight, net	0.7 kg / 1.543 lb

Regulatory Compliance/Certifications

ISO 9001:2015	Designed, manufactured and/or distributed under this quality management system
ROHS	Compliant
CHINA-ROHS	Below maximum concentration value
REACH-SVHC	Compliant as per SVHC revision on www.commscope.com/ProductCompliance

Documents and Downloads
