Commscope FGS-MD4E-H | FiberGuide 45° Down Elbow, 4x24in, Yellow
Regular price
$451.33
Unit price
Brand: CommScope
|
SKU:
932836
Regular price
$451.33
Unit price
Description
Description
FiberGuide 45° Down Elbow, 4x24in, Yellow
Specifications
Specifications
Product Classification
| Regional Availability | Asia | Australia/New Zealand | EMEA | Latin America | North America |
|---|---|
| Portfolio | CommScope |
General Specifications
| Angle/Bend Direction | 45° down |
|---|---|
| Color | Yellow |
| Orientation | Horizontal |
| Section Type | Elbow section |
Dimensions
| Height | 117 mm | 4.606 in |
|---|---|
| Width | 647 mm | 25.472 in |
| System Dimensions | 102 mm x 610 mm (4 in x 24 in) |
Material Specifications
| Material Type | Engineering Thermoplastic |
|---|
Environmental Specifications
| Flammability Rating | CSA S143 | UL 2024 | UL 94 V-0 |
|---|---|
| Halogen Characteristics | Blue Angel | TCO '99 | WEEE |
| Safety Standard | CSA | UL |
Packaging and Weights
| Weight, net | 1.583 kg | 3.490 lb |
|---|
Regulatory Compliance/Certifications
| ROHS | Compliant |
|---|---|
| CHINA-ROHS | Below maximum concentration value |
| REACH-SVHC | Compliant as per SVHC revision on www.commscope.com/ProductCompliance |
