Brand: CommScope
|
SKU:
372-COMOS2-HPFC12-12
CommScope PFC-S12O12 | Powered Fiber Cable, OS2, 12 Fibers, Outdoor, 12AWG Conductor, meter, feet
Regular price
$3.00
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
CommScope PFC-S12O12 | Powered Fiber Cable, OS2, 12 Fibers, Outdoor...
Regular price
$3.00
Unit price
Brand: CommScope
|
SKU:
372-COMOS2-HPFC12-12
Regular price
$3.00
Unit price
Shipping calculated at checkout.
Description
Description
CommScope PFC-S12O12 | Powered Fiber Cable, OS2, 12 Fibers, Outdoor, 12AWG Conductor, meter, feet
Specifications
Specifications
CommScope - PFC-S12O12 - Product Categories
- Cables
- Hybrid Cables
CommScope - PFC-S12O12 - General Specifications
| Brand Name | CommScope |
|---|---|
| Manufacturer Part Number | PFC-S12O12 |
| Item Description | Powered Fiber Cable, OS2, 12 Fibers, Outdoor, 12AWG Conductor, meter, feet |
| Cable Type | Stranded outdoor |
| Fiber Short Description | PFC-O12 |
| Jacket Color | Black |
| Total Fiber Count | 12 |
CommScope - PFC-S12O12 - Product Classification
| Regional Availability | Asia | Australia/New Zealand | EMEA | Latin America | North America |
|---|---|
| Product Type | Hybrid cable, fiber and power |
| Ordering Note | Minimum order quanity is 500 meter |
CommScope - PFC-S12O12 - Physical Specifications
| Dimensions | - |
|---|---|
| Height Over Jacket | 4.318 mm | 0.17 in |
| Width Over Jacket | 11.43 mm | 0.45 in |
| Conductor Gauge | 12 AWG |
| Mechanical Specifications | - |
| Minimum Bend Radius, loaded | 50.8 mm | 2 in |
| Minimum Bend Radius, unloaded | 30.48 mm | 1.2 in |
| Tensile Load, long term, maximum | 133.447 N | 30 lbf |
| Tensile Load, short term, maximum | 440.374 N | 99 lbf |
| Vertical Rise, maximum | 122.011 m | 400.3 ft |
| Optical Specifications | - |
| Fiber Type | G.657.A2, TeraSPEED |
| Environmental Specifications | - |
| Installation temperature | -10 °C to +60 °C (+14 °F to +140 °F) |
| Operating Temperature | -40 °C to +70 °C (-40 °F to +158 °F) |
| Storage Temperature | -40 °C to +70 °C (-40 °F to +158 °F) |
| Cable Qualification Standards | Telcordia GR-20-CORE Issue 4 |
| Environmental Space | Outdoor |
| Jacket UV Resistance | UV stabilized |
| Packaging and Weights | - |
| Cable weight | 109.975 kg/km | 73.9 lb/kft |
| Regulatory Compliance/Certifications | - |
| Agency | Classification |
| ROHS | Compliant |
| CHINA-ROHS | Below maximum concentration value |
| REACH-SVHC | Compliant as per SVHC revision on www.commscope.com/ProductCompliance |
| UK-ROHS | Compliant |
