Comnet CNFE8TX8US Unmanaged Switch, 8 Port, 100Mbps, 8 Copper

The ComNet™ CNFE8US Series Ethernet 8 port unmanaged switch is designed to transmit and receive 10/100 Mbps data over optical fiber through user selectable SFP options or 10/100 Mbps data over CAT5E/6 electrical cable. This unit integrates eight independent 10/100 Mbps channels in a single package. The CNFE8FX4TX4US and CNFE8FX8US require the ordering of sold-separately interchangeable SFP modules for fiber type, distance and connectors. All electrical interfaces will Auto-Negotiate to 10 Mbps, or 100 Mbps Ethernet rate without any adjustments. The optical interfaces operate at a 100 Mbps Ethernet rate. The CNFE8US Series models are environmentally hardened to operate in demanding environments. LED indicators are provided for confirming equipment operating status. These units are interchangeable between stand-alone or card mount configurations.

Features

10/100/1000 Mbps Ethernet

All ports support 1000 Mbps full duplex data

Automatic MDI/MDI-X crossover

Designed to meet full compliance with the environmental requirements (ambient operating temperature, mechanical shock, vibration, humidity with condensation, high-line/low-line voltage conditions and transient voltage protection) of

NEMA TS-1/TS-2 and the Caltrans Specification for Traffic Signal Control Equipment.

No In-field optical adjustments required

Voltage transient protection on all power and signal input/output lines provides unconditional protection from power surges and other voltage transient events.

Power and Port status LED indicators

IEEE 802.3 compliant

Hot-swappable rack modules

Interchangeable between stand-alone or rack mount use ComFit

Specs

Manufacturer Comnet Communication Networks

Condition New

Data Interface Ethernet

Surface Mount 9-24 VDC @ 700 mA

Rack Mount From Rack

Power Terminal Block

Optical LC or SC (depending on SFP module used)

Surface Mount 9-24 VDC @ 700 mA

Circuit Board Meets IPC Standard

MTBF >100,000 hours

Operating Temp -40? C to +75? C

Storage Temp -40? C to +85? C

Relative Humidity 0% to 95% (non-condensing)†
