Comnet FVT4012M1 | Transmitter 4 Video/2 Bi-Directional Data/1 Contact Closure, Multimode
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Comnet FVT4012M1 | Transmitter 4 Video/2 Bi-Directional Data/1 Cont...
Description
Description
The ComNet FVT/FVR4012(M)(S)1 Series transmits four (4) channels of video utilizing state of the art 10-bit digital encoding and decoding for very high quality video transmission, along with two (2) channels of bi-directional data and one (1) bi-directional contact closure over one single mode or multimode optical fiber.
This equipment is environmentally hardened and suitable for use in unconditioned roadside or out-of plant installations.
The FVT/FVR4012 is compatible with NTSC, PAL and SECAM video transmission protocols and supports bi-directional RS232, 422 and 485-2/4W data.
Plug-and-play design ensures ease of installation and no electrical or optical adjustments are required.
Bi-Color LED indicators are provided to indicate the status of the system, video and data.
Packaged in the exclusive ComNet ComFit housing, these units may be either wall or rack-mounted, or may be DIN-rail mounted by the addition of ComNet model DINBKT1 adaptor plate.
No additional parts or power supplies are required.
Comnet - FVT4012M1 - Features
- 10-Bit Digitally Encoded Video Transmission Transmits 4 Real-Time Color Video Signals and 2 Bi-Directional Data Signals on One Optical Fiber
- Exceeds All Requirements for RS-250C Short Haul Transmission High Quality Video Performance
- One Bi-Directional Contact Closure
- Compatible with All NTSC, PAL or SECAM CCTV Camera Systems
- Voltage Transient Protection on All Power and Signal Input/Output Lines Provides Unconditional Protection from Power Surges and Other Voltage Transient Events
- Robust Design Ensres Extremely High Reliability in Unconditioned Out-of-Plant Environments
- Bi-Color (Red/Green) LED Status Indicators Provide Rapid Indication of Critical Operating Parameters
- Hot-Swappable Rack Modules
- Interchangeable Between Stand-Alone or Rack MountUse ComFit
- Lifetime Warranty
- Made in USA
Specifications
Specifications
Comnet - FVT4012M1 - Specifications
| UNSPSC Code | 46171600 |
|---|
