Brand: Corning
|
SKU:
372-COROS2-LTDSS-02
Corning 002ZBA-14101A20 | SST-Drop Single-Tube, Self-Supporting, Gel-Filled Cable 2 F, SMF-28 Ultra fiber, Single-mode (OS2)
Regular price
$1.46
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Corning 002ZBA-14101A20 | SST-Drop Single-Tube, Self-Supporting, Ge...
Regular price
$1.46
Unit price
Brand: Corning
|
SKU:
372-COROS2-LTDSS-02
Regular price
$1.46
Unit price
Shipping calculated at checkout.
Description
Description
Corning 002ZBA-14101A20 | SST-Drop Single-Tube, Self-Supporting, Gel-Filled Cable 2 F, SMF-28 Ultra fiber, Single-mode (OS2)
Specifications
Specifications
Corning - 002ZBA-14101A20 - Product Categories
- Fiber Optic Cables
- Outdoor
- Outdoor Aerial Cables
Corning - 002ZBA-14101A20 - Specifications
| Brand Name | Corning |
|---|---|
| Manufacturer Part Number | 002ZBA-14101A20 |
| Item Description | SST-Drop Single-Tube, Self-Supporting, Gel-Filled Cable 2 F, SMF-28 Ultra fiber, Single-mode (OS2) |
| General Specifications | - |
| Product Number | 002ZBA-14101A20 |
| Environment | Outdoor |
| Cable Type | Drop |
| Product Type | Self-Supporting |
| Fiber Category | SMF-28 Ultra fiber |
| Application | Self-Supporting |
| Fiber Count | 2 |
| Standards | - |
| RoHS | Free of hazardous substances according to RoHS 2011/65/EU |
| Approvals and Listings | USDA Rural Development Programs |
| Design and Test Criteria | ANSI/ICEA S-110-717, Telcordia GR-20-CORE |
| Environmental Conditions | - |
| Temperature Range, Installation | -30°C to 70°C (-22°F to 158°F ) |
| Temperature Range, Operation | -40°C to 70°C (-40°F to 158°F ) |
| Temperature Range, Storage | -40°C to 70°C (-40°F to 158°F ) |
| Cable Design | - |
| Fiber Count | 2 |
| Outer Jacket Color | Black |
| Outer Jacket Material | Polyethylene (PE) |
| Tensile Strength Elements and/or Armoring - Layer 1 | Dielectric strength members |
| Buffer Tube Color | Natural |
| Buffer Tube Diameter | 3mm (0.12in) |
| Tensile Strength Elements and/or Armoring | Dielectric strength members |
| Fiber Coloring | Blue, Orange |
| Color Code Standards | Telcordia |
| Mechanical Specifications | - |
| Max. Tensile Strength, Long-Term | 400N (89.92lbf) |
| Max. Tensile Strength, Short-Term | 1350N (303.49lbf) |
| Min. Bend Radius Operation | 135mm (5.31in) |
| Nominal Outer Diameter | 12.3mm x 4.4mm (0.48in x 0.17in) |
| Optical Characteristics | - |
| Fiber Code | Z |
| Fiber Name | SMF-28 Ultra fiber |
| Fiber Type | Single-mode |
| Performance Option Code | 01 |
| Maximum Attenuation | 0.4 dB/km / 0.4 dB/km / 0.3 dB/km |
| Wavelengths | 1310 nm / 1383 nm / 1550 nm |
| Fiber Category | ITU-T G.657.A1 |
| Dimensions | - |
| Cable Weight | 525kg/km (352.78lb/1000 ft) |
