Corning 024E81-33131-A1 | Mic Tight-Buffered, Interlocking Armored ...
Description
Description
Corning MIC interlocking armored riser cables are designed for use in intrabuilding backbone and horizontal installations. They use individually jacketed 900 um buffered fibers enabling easy, consistent stripping and facilitating termination. The fiber s are grouped into 6-, 12-, or 24-fiber jacketed subunits and surrounded by a dielectric central member. The core is protected by a flexible, spirally wrapped, aluminum interlocking armor that offers easy, one-step installation and up to six times the crush protection of non-interlocking armored cables. With a flame-retardant outer jacket, this cable is particularly useful for heavy traffic or more challenging mechanical exposure conditions and applications requiring extra rugged cables.
This cable is available in 12 different jacket colors - blue, orange, green, brown, slate, white, red, black, yellow, violet, rose and aqua. The colored jacket allows for easy visual identification of the cables. The standard jacket color will be determined by t he dominant fiber type in the cable and will use the standard part numbers shown here. Contact Customer Care at 1-800-743-2675 to order other color options.
Corning - 024E81-33131-A1 - Features
- Flexible, interlocking armor design
- Six times crush protection Buffered fibers
- Easy, consistent stripping Flame-retardant jacket
- Rugged and durable
- General Purpose Horizontal, Vertical Riser
Specifications
Specifications
Corning - 024E81-33131-A1 - Specification Description
- Cable Type: Tight-Buffered
- Environment: Indoor
- Fiber Category: Single-mode (OS2)
- Flame Rating: Riser (OFCR)
- Product Type: Interlocking armor
- Central Element: Yarn
- Fiber Count (cable): 24
- Inner Jacket Material: Flame-retardant
- Number of Ripcords: 2
- Outer Jacket Color: Yellow
- Outer Jacket Material: Flame-retardant
- Tensile Strength Elements and/or Armoring - Layer 1: Dielectric strength members
- Tensile Strength Elements and/or Armoring - Layer 2: Dielectric strength members
- Tensile Strength Elements and/or Armoring - Layer 3: Interlocking armor
- Tight Buffer Color, Layer 2: Violet, Rose, Aqua, Blue*, Orange*, Green*, Brown*, Slate*, White*, Red*, Black*, Yellow*, Violet*, Rose*, Aqua*
- Tight Buffer Color: Blue, Orange, Green, Brown, Slate, White, Red, Black, Yellow
- Max. Tensile Strengths, Long-Term (Metric): 400 N
- Max. Tensile Strengths, Long-Term (US): 90 lbf
- Max. Tensile Strengths, Short-Term (Metric): 1320 N
- Max. Tensile Strengths, Short-Term (US): 300 lbf
- Min. Bend Radius Installation (Metric): 225 mm
- Min. Bend Radius Installation (US): 8.9 in
- Min. Bend Radius Operation (Metric): 150 mm
- Min. Bend Radius Operation (US): 5.9 in
- Nominal Inner Cable Diameter (Metric): 8 mm
- Nominal Inner Cable Diameter (US): 0.31 in
- Nominal Outer Diameter (Metric-mm): 15 mm
- Nominal Outer Diameter (US): 0.59 in
- Weight (cable) (Metric): 183 kg/km
- Weight (cable) (US): 123 lb/1000 ft
- Temperature - Installation (Metric): -10 C to 60 C
- Temperature - Installation (US): 14 F to 140 F
- Temperature - Operation (Metric): -20 C to 70 C
- Temperature - Operation (US): -4 F to 158 F
- Temperature - Storage (Metric): -40 C to 70 C
- Temperature - Storage (US): -40 F to 158 F
- Tech Info
- Approval and Listings: National Electrical Code (NEC) OFCR, CSA FT-4, ICEA S-83-596; Flame Resistance: UL-1666 (for riser and general building applications)
Corning - 024E81-33131-A1 - Specifications
| Armored | Yes |
|---|---|
| Cable Type | Tight Buffered |
| Fiber Count | 24 |
| Fiber Type | Os2 Single-Mode |
| Fire Rating | Riser |
| UNSPSC Code | 26121607 |
