Brand: Corning
|
SKU:
371-COROM4-TBR-24
Corning 024T81-33191-24 | MIC Tight-Buffered Cable, Riser 24 F, 50 µm multimode, extended 10G distance (OM4)
Regular price
$8.74
Unit price
Shipping calculated at checkout.
-
Low prices.
Price match guarantee
-
In-House Experts.
We know our products
-
Easy Returns.
Quick & Hassle Free
-
Superior Selection.
Extensive product catalog
Corning 024T81-33191-24 | MIC Tight-Buffered Cable, Riser 24 F, 50...
Regular price
$8.74
Unit price
Brand: Corning
|
SKU:
371-COROM4-TBR-24
Regular price
$8.74
Unit price
Shipping calculated at checkout.
Description
Description
Corning 024T81-33191-24 | MIC Tight-Buffered Cable, Riser 24 F, 50 µm multimode, extended 10G distance (OM4)
Specifications
Specifications
Corning - 024T81-33191-24 - Product Categories
- Fiber Optic Cables
- Indoor
- Indoor Riser Cables
Corning - 024T81-33191-24 - Specifications
| Brand Name | Corning |
|---|---|
| Manufacturer Part Number | 024T81-33191-24 |
| Item Description | MIC Tight-Buffered Cable, Riser 24 F, 50 µm multimode, extended 10G distance (OM4) |
| General Specifications | - |
| Product Number | 024T81-33191-24 |
| EAN Code | 4056418149141 |
| Environment | Indoor |
| Cable Type | Tight-Buffered |
| Product Type | Distribution |
| Fiber Category | 50 µm MM (OM4+) |
| Flame Rating | Riser (OFNR) |
| Application | General Purpose Horizontal, Vertical Riser |
| Fiber Count | 24 |
| Standards | - |
| RoHS | Free of hazardous substances according to RoHS 2011/65/EU |
| Approvals and Listings | National Electrical Code (NEC) OFNR, UL 1666, CSA FT-4, ICEA S-83-596 |
| Flame Test Method | UL-1666 and CSA FT-4 (for riser and general building applications), ICEA S-83-596 |
| Environmental Conditions | - |
| Temperature Range, Installation | -10°C to 60°C (14°F to 140°F ) |
| Temperature Range, Operation | -20°C to 70°C (-4°F to 158°F ) |
| Temperature Range, Storage | -40°C to 70°C (-40°F to 158°F ) |
| Cable Design | - |
| Central Element | Yarn |
| Fiber Count | 24 |
| Outer Jacket Color | Aqua |
| Outer Jacket Material | Flame-retardant |
| Tensile Strength Elements and/or Armoring - Layer 1 | Dielectric strength members |
| Tensile Strength Elements and/or Armoring - Layer 2 | Dielectric strength members |
| Tight Buffer Color | Blue, Orange, Green, Brown, Slate, White, Red, Black, Yellow |
| Flame Rating | Riser (OFNR) |
| Mechanical Specifications | - |
| Max. Tensile Strength, Long-Term, ?12F | 200N (44.96lbf) |
| Max. Tensile Strength, Long-Term, >12F | 400N (89.92lbf) |
| Max. Tensile Strength, Short-Term, ?12F | 660N (148.37lbf) |
| Max. Tensile Strength, Short-Term, >12F | 1320N (296.75lbf) |
| Min. Bend Radius Installation | 110.25mm (4.34in) |
| Min. Bend Radius Operation | 73.5mm (2.89in) |
| Nominal Outer Diameter | 7.35mm (0.29in) |
| Optical Characteristics | - |
| Fiber Code | T |
| Fiber Type | Multimode |
| Performance Option Code | 91 |
| Fiber Core Diameter | 50µm |
| Minimum Effective Modal Bandwidth (EMB) | 5350 MHz*km / - |
| Maximum Attenuation | 2.8 dB/km / 1.0 dB/km |
| Min. Overfilled Launch (OFL) Bandwidth | 3500 MHz*km / 500 MHz*km |
| Serial 1 Gigabit Ethernet | 1100 MHz*km / 600 MHz*km |
| Serial 10 Gigabit Ethernet | 600 MHz*km / - |
| Wavelengths | 850 nm / 1300 nm |
| Fiber Category | OM4 Extended Distance |
| Dimensions | - |
| Cable Weight | 47kg/km (31.58lb/1000 ft) |
